CS6080

Description

The CS60 wireless reader is ideal for in-store inventory; Its size makes it easy to slip into a pocket; What’s more, it can be recharged contact-free, making everyday life even easier;

Versatile, it will adapt to all your needs throughout the day: wired or wireless, portable or hands-free, thanks to the optional presentation stand; This minimizes investment risk, because it’s easy to meet new workflow requirements or redeploy CS60 scanners to another application;

Its high-resolution megapixel sensor and exclusive intelligent imaging technology will enable you to read barcodes, even those that are poorly printed, damaged, dirty, creased… and even on cell phone screens.

A second programmable button allows your employees to switch immediately between 2 applications;

With best-in-class IP65 waterproofing and a 5 ft/1.5 m drop specification, the CS60 is designed for durability and availability;

  • Dimensions Scanner : 0.9 in. H x 1.8 in. W x 4.3 in. D / 2.3 cm H x 4.6 cm W x 10.9 cm D
  • Standard Cradle : 4.5 in. H x 3.1 in. W x 4.2 in. D / 11.3 cm H x 7.8 cm W x 10.7 cm D
  • Weight Corded CS60 : 2.0 oz. / 56.0 g
  • Cordless CS60 : 2.9 oz. / 83.0 g
  • Standard Cradle : 4.9 oz. / 138.0 g
  • Input Voltage Range Scanner and standard cradle : 4.5 to 5.5 VDC Host Powered; 4.5 to 5.5 VDC External Power Supply
  • Operating current at nominal voltage (5.0V) : 400 mA (typical)
  • Standby current (idle) at nominal voltage (5.0V) : 90 mA (typical)
  • Standard Cradle : 450 mA (typical) Standard USB ; 600 mA (typical) BC 1.2 USB
  • Color : Midnight black
  • Supported Host Interfaces : USB
  • Keyboard Support : Supports over 90 international keyboards
  • User Indicators : Direct Decode Indicator, Good Decode LEDs, beeper (adjustable tone and volume), haptic feedback on decode, capacitive trigger with haptic and audible feedback, dedicated battery gauge, dedicated, Bluetooth LED
  • Motion Tolerance (handheld) : Up to 20 in. / 51 cm per second for 13 mil UPC in optimized mode
  • Light Source : Aiming Pattern : circular 525nm true green LED
  • Illumination : warm white LED
  • Imager Field of View : 45° H x 34° V nominal
  • Image Sensor : 1280 x 960 pixels
  • Minimum Print Contrast : 20% Minimum Reflective Distance
  • Skew Tolerance : +/- 60°
  • Pitch Tolerance : +/- 60°
  • Roll Tolerance : 0° - 360°
  • Minimum Element Resolution : Code 39 - 5.0 mil
  • Operating Temp. : 32° F to 122° F / 0° C to 50° C
  • Storage Temp. : -40° F to 158° F / -40° C to 70° C
  • Humidity : 5% to 95% RH, non-condensing
  • Drop Specification : Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete
  • Tumble Specification : Designed to withstand 250 tumbles in 1.5 ft./0.5 m tumbler (1 tumble = 0.5 cycle)
  • Sealing Scanner : IP65
  • Electrostatic Discharge (ESD) : Scanner and cradle: ESD per EN61000-4-2, +/-15 KV, Air, +/-8 KV Direct, +/-8 KV Indirect
  • Ambient Light Immunity : 0 to 10037 foot candles / 0 to 108,000 Lux
  • Bluetooth Radio Standard Bluetooth Version 5.0 with BLE : Class 1
  • 330ft. (100m) and Class 2 33ft. (10m), Serial Port and HID Profiles
  • Adjustable Bluetooth Power : Output power adjustable down to negative 10 dBm in 8 steps
  • Battery Capacity/Type : 735 mAh Lithium Polymer battery
  • Scans Per Battery Charge : 13,000 scans
  • Operating Time Per Full Charge : 18 hours
  • Standard USB Full Charge : 6 hours
  • BC1.2 USB Full Charge : 3 hours
  • Environmental : EN 50581:2012 / EN IEC 63000 :2018
  • Electrical Safety : IEC 62368-1 (Ed.2) / EN 62368-1:2014/AC:2015
  • LED Safety : IEC 62471:2006 (Ed.1.0) / EN 62471:2008 (LED)
  • EMI/RFI : EN 55032:2015/AC:2016 (Class B) / EN 55035:2017 / EN 61000-3-2:2014 (Class A) / EN 61000-3-3:2013 / 47 CFR Part 15, Subpart B, Class B
  • Cordless Accessories : Standard cradle, spare battery, 4-slot scanner, ShareCradle, 4-slot battery ShareCradle, lanyard
  • Corded Accessories : Gooseneck Intellistand (weighted and standard), cup, corded USB converter
  • 1D : Base 32 (Italian Pharma), Codabar/NW7, Code 11, Code 39, Code 93, Code 128, GS1 DataBar, I 2 of 5, Korean 3 of 5, MSI Plessey, UPC/EAN
  • 2D : Aztec, Composite Codes, DataMatrix, Dotted, DataMatrix, Dotcode, Han Xin, MaxiCode, PDF417, Micro PDF417, Postal Codes, QR Code, Micro QR, TLC-39, SecurPharm
  • OCR : OCR-A, OCR-B, MICR, US Currency
  • Refer to Product Reference Guide for complete list of symbologies.
Contactez-nous
  • Symbology/Resolution Near/Far :
    • Code 39 : 5 mil 2.4 in. / 6.1 cm to 9.5 in./24.1 cm
    • Code 39 : 20 mil 2.5 in. / 6.4 cm to 26.0 in./66.0 cm
    • Code 128 : 5 mil 2.8 in. / 7.1 cm to 9.0 in./22.9 cm
    • PDF 417 : 6.7 mil 2.4 in. / 6.1 cm to 8.0 in./20.3 cm
    • UPC : 13 mil (100%) 1.8 in. / 4.6 cm to 19.5 in./49.5 cm
    • Data Matrix : 10 mil 2.9 in. / 7.4 cm to 8.0 in./20.3 cm
    • QR : 20 mil 1.2 in./3.0 cm to 14 in./35.6 cm
