FX9600

Description

The FX9600 industrial fixed UHF RFID reader from ZEBRA offers the performance and functionality you need to track all the tagged items that pass through your business every day. This reader also offers a state-of-the-art read rate, exceptional reading accuracy and superior RF sensitivity. Efficient and precise, it will be your best RFID asset.

Request a quote
  • Technical specifications

  • PHYSICAL CHARACTERISTICS

    • Dimensions : 10.75 in. L x 7.25 in. W x 2.0 in. D / 27.3 cm L x 18.4 cm W x 5 cm D
    • Weight Approx. : 4.4 lbs / 2.13 kg
    • Housing Material : Die-cast aluminum, meets IP53 standards
    • Visual Status Indicators : Multicolor LEDs: Power, Activity, Status and Applications

    RFID CHARACTERISTICS

    • Max Receive Sensitivity : -86 dBm monostatic
    • Air Protocols : ISO 18000-63 (EPC Class 1 Gen 2 V2)
    • Frequency (UHF Band) : Global Reader: 902 MHz – 928 MHz (Also supports countries that use a part of this band), 865 MHZ – 868 MHz US (only) Reader: 902 – 928 MHz
    • Transmit Power : Output 0 dBm to +33 dBm (POE+ 802.3at, Universal 24V DC Power Supply) / 0 dBm to +31.5 dBm (POE 802.3af)

    CONNECTIVITY

    • Communications 10/100 BaseT Ethernet (RJ45); USB Host & Client (Type A & B); Serial (DB9)
    • General Purpose I/O 4 inputs, 4 outputs, optically isolated (Terminal Block)
    • Power Supply : POE (802.3af) / POE+ (802.3at) +24V DC (UL Approved)
    • Antenna Ports FX9600-4: 4 monostatic ports; (Reverse Polarity TNC) FX9600-8: 8 monostatic ports; (Reverse Polarity TNC)

    ENVIRONMENTAL

    • Operating Temp. -4° to +131° F/-20° to +55° C
    • Storage Temp. -40° to +158° F/-40° to +70° C
    • Humidity 5-95% non-condensing
    • Sealing IP53

    HARDWARE, OS AND FIRMWARE MANAGEMENT

    • Processor : Texas Instruments AM3505 (600 Mhz)
    • Memory Flash : 512 MB; DRAM 256 MB
    • Operating System : Linux
    • Firmware Upgrade : Web-based and remote firmware upgrade capabilities
    • Management Protocols : RM 1.0.1 (with XML over HTTP/HTTPS and SNMP binding); RDMP
    • Network Services : DHCP, HTTPS, FTPS, SFPT, SSH, HTTP, FTP, SNMP and NTP
    • Network Stack : IPv4 and IPv6
    • Security : Transport Layer Security Ver 1.2, FIPS-140
    • API Support : Host Applications – .NET, C and Java EMDK Embedded Applications – C and Java SDK

    REGULATORY COMPLIANCE

    • Safety : UL 60950-01, UL 2043, IEC 60950-1, EN 60950-1
    • RF/EMI/EMC : FCC Part 15, RSS 210, EN 302 208, ICES-003 Class B, EN 301 489-1/3
    • For Malaysia: 919-923 MHz
    • SAR/MPE : FCC 47CFR2:OET Bulletin 65; EN 50364
    • Other : ROHS, WEEE
