Reader CPR02.10

Description

The CPR02.10 is designed as a wall-mounted card reader for contactless data exchange with ISO 14443-A/-B and ISO 15693 transponders. Typical applications are access control and time management. The card reader requires an external power supply. For data exchange with a computer or host system, the following communication links are available: RS232 or RS485 and Data / Clock.

  • Dimensions: card reader 84 x 84 x 22 mm, weight approx. 150 g / wall housing 78 x 78 x 18 mm
  • Material: plastic (ASA), acrylic glass front, white & black
  • Protection class: IP54
  • Operating temperature: -25 °C to +60 °C
  • Storage temperature: -40 °C to +85 °C
  • Supply voltage: 12-24 V AC / DC
  • Energy consumption: max; 2.6 W
  • Communication links: RS232 and Data / Clock, RS485
  • Optical indicators: multicolor (red / green / orange)
  • Puissance RF : 250 mW +/- 2 dB
  • Frequency: 13.56 MHz
  • Antenne : interne, 70 mm x 70 mm
  • Reading distance: max. 7 cm
  • Transponder support: ISO 14443-A/-B, ISO 15693, NFC
